Measurements and Results

R&S

FSW

277User Manual 1173.9411.02 ─ 43

Child Node Attribute Value Parameter Description Mand.

Reference-

Power

Yes

Method TX Channel Power |

TX Channel Peak

Power

Yes

Reference-

Channel

Table 7-15: Attributes and child nodes of the PowerClass element

Child Node Attribute Value Parameter description Mand.

StartPower Value <power in dBm> The start power must be equal

to the stop power of the previ-

ous power class. The Start-

Power value of the first range

is -200

Yes

Unit dBm

Yes

InclusiveFlag true

Yes

StopPower Value <power in dBm> The stop power must be equal

to the start power of the next

power class. The StopPower

value of the last range is 200

Yes

Unit dBm

InclusiveFlag false

Yes

DefaultLimitFailMode

Absolute | Relative

| Absolute and Rel-

ative | Absolute or

Relative

Yes

Table 7-16: Attributes and child nodes of the Range element (normal ranges)

Child node Attribute Value Parameter description Mand.

Index 0…19 Indices are continuous and

have to start with 0

Yes

Name <string> Name of the range Only if Referen-

ceChannel con-

tains a name and

the range is the

reference range

Short-

Name

<string> Short name of the range No

ChannelType

TX | Adjacent

Yes

WeightingFilter

Only if Referen-

cePower method

is TX Channel

Power and the

range is the ref-

erence range

Spectrum Emission Mask (SEM) Measurement
