Common Measurement Settings
R&S
®
FSW
386User Manual 1173.9411.02 ─ 43
Generator
type
Model Driver file TTL sup-
port
Generator type Model Driver file TTL sup-
port
6 GHz SME06 X 4 GHz
SMU04
2)
X
SMF100A 43.5 GHz SMF100A X 4 GHz
SMU04B31
2)
X
SMF 22 GHz SMF22 X 6 GHz
SMU06
2)
X
22 GHz SMF22B2 X 6 GHz
SMU06B31
2)
X
43 GHz SMF43 X SMV 3 GHz SMV03 -
43 GHz SMF43B2 X SMW 3 GHz SMW03
X
4)
SMG all SMG - 6 GHz SMW06
X
4)
SMGL all SMGL - 12.75 GH
z
SMW12
X
4)
SMGU all SMGU - 20 GHz SMW20
X
4)
SMH all SMH - 31.8 GHz SMW31
X
4)
SMHU SMHU - 40 GHz SMW40
X
4)
SMIQ 2 GHz SMIQ02 X SMX all SMX -
2 GHz SMIQ02B X SMY 1 GHz SMY01 -
2 GHz SMIQ02E - 2 GHz SMY02 -
3 GHz SMIQ03 X
3 GHz SMIQ03B X
3 GHz SMIQ03E -
4 GHz SMIQ04B X
6 GHz SMIQ06B X
1) Requires firmware version V2.10.x or higher on the signal generator
2) Requires firmware version V1.10.x or higher on the signal generator
3) Requires the option SMR-B11 on the signal generator
4) Requires firmware version V3.20.200 or higher on the signal generator
Generator Setup Files
For each signal generator type to be controlled by the R&S FSW a generator setup file
must be configured and stored on the R&S FSW. The setup file defines the frequency
and power ranges supported by the generator, as well as information required for com-
munication. For the signal generators listed in "Overview of Supported Generators"
on page 385, default setup files are provided. If necessary, these files can be edited or
duplicated for varying measurement setups or other instruments.
The existing setup files can be displayed in an editor in read-only mode directly from
the "External Generator" configuration dialog box. From there, they can be edited and
stored under a different name, and are then available on the R&S FSW.
(For details see "To define a new generator setup file" on page 402).
Data Input and Output
