Overview of Supported Generators
Generator
type
Model Driver file TTL sup-
port
Generator type Model Driver file TTL sup-
port
SGS100A 6 GHz SGS100A6 - SMJ 3 GHz SMJ03 X
12 GHz SGS100A12 - 6 GHz SMJ06 X
SGT100A 3 GHz SGT100A3 - SML 1 GHz SML01 -
6 GHz SGT100A6 - 2 GHz SML02 -
SMA01A 3 GHz
SMA01A
1)
X 3 GHz SML03 -
SMA100A 3 GHz SMA100A3 X SMP 2 GHz SMP02 X
6 GHz SMA100A6 X 3 GHz SMP03 X
SMA100B 3 GHz SMA100B3 X 4 GHz SMP04 X
6 GHz SMA100B6 X 22 GHz SMP22 X
12 GHz SMA100B12 X SMR 20 GHz SMR20 -
20 GHz SMA100B20 X 20 GHz
SMR20B11
3)
X
SMB100A 1 GHz SMB100A1 X 27 GHz SMR27 X
12 GHz SMB100A12 X 27 GHz
SMR27B11
3)
X
2 GHz SMB100A2 X 30 GHz SMR30 X
20 GHz SMB100A20 X 30 GHz
SMR30B11
3)
X
3 GHz SMB100A3 X 40 GHz SMR40 X
40 GHz SMB100A40 X 40 GHz
SMR40B11
3)
X
SMB100B 1 GHz SMB100B1 X 50 GHz SMR50 X
3 GHz SMB100B3 X 50 GHz
SMR50B11
3)
X
6 GHz SMB100B6 X 60 GHz SMR60 X
SMBV100A 3 GHz SMBV100A3 X 60 GHz
SMR60B11
3)
X
6 GHz SMBV100A6 X SMT 2 GHz SMT02 -
SMBV100B 3 GHz SMBV100B3 X 3 GHz SMT03 -
6 GHz SMBV100B6 X 6 GHz SMT06 -
SMC100A 1 GHz SMC100A1 - SMU 2 GHz SMU02 X
3 GHz SMC100A3 - 2 GHz
SMU02B31
2)
X
SME 2 GHz SME02 X 3 GHz
SMU03
2)
X
3 GHz SME03 X 3 GHz
SMU03B31
2)
X
1) Requires firmware version V2.10.x or higher on the signal generator
2) Requires firmware version V1.10.x or higher on the signal generator
3) Requires the option SMR-B11 on the signal generator
4) Requires firmware version V3.20.200 or higher on the signal generator
