Network and Remote Operation
R&S
®
FSW
733User Manual 1173.9411.02 ─ 43
For details on configuring the LAN connection, see Chapter 13.6.1, "How to Configure
a Network", on page 797.
● VXI-11 Protocol..................................................................................................... 733
● HiSLIP Protocol.....................................................................................................733
● Socket Communication......................................................................................... 733
● LXI Web Browser Interface................................................................................... 734
VXI-11 Protocol
The VXI-11 standard is based on the ONC RPC (Open Network Computing Remote
Procedure Call) protocol which in turn relies on TCP/IP as the network/transport layer.
The TCP/IP network protocol and the associated network services are preconfigured.
TCP/IP ensures connection-oriented communication, where the order of the
exchanged messages is adhered to and interrupted links are identified. With this proto-
col, messages cannot be lost.
HiSLIP Protocol
The HiSLIP (High Speed LAN Instrument Protocol) is the successor protocol for
VXI-11 for TCP-based instruments specified by the IVI foundation. The protocol uses
two TCP sockets for a single connection - one for fast data transfer, the other for non-
sequential control commands (e.g. Device Clear or SRQ).
HiSLIP has the following characteristics:
●
High performance as with raw socket network connections
●
Compatible IEEE 488.2 support for Message Exchange Protocol, Device Clear,
Serial Poll, Remote/Local, Trigger, and Service Request
●
Uses a single IANA registered port (4880), which simplifies the configuration of fire-
walls
●
Supports simultaneous access of multiple users by providing versatile locking
mechanisms
●
Usable for IPv6 or IPv4 networks
Using VXI-11, each operation is blocked until a VXI-11 device handshake returns. How-
ever, using HiSLIP, data is sent to the device using the "fire and forget" method with
immediate return. Thus, a successful return of a VISA operation such as viWrite()
does not guarantee that the instrument has finished or started the requested com-
mand, but is delivered to the TCP/IP buffers.
For more information see also the application note:
1MA208: Fast Remote Instrument Control with HiSLIP
Socket Communication
An alternative way for remote control of the software is to establish a simple network
communication using sockets. The socket communication, also referred to as "Raw
Ethernet communication", does not necessarily require a VISA installation on the
remote controller side. It is available by default on all operating systems.
Remote Control Basics
