Remote Commands
R&S
®
FSW
824User Manual 1173.9411.02 ─ 43
INSTrument:MODE........................................................................................................ 827
INSTrument:REName.....................................................................................................827
INSTrument[:SELect]......................................................................................................828
DISPlay:ATAB <State>
This command switches between the MultiView tab and the most recently displayed
channel. If only one channel is active, this command has no effect.
Parameters:
<State> ON | OFF | 0 | 1
OFF | 0
Switches the function off
ON | 1
Switches the function on
INSTrument:CREate:DUPLicate
This command duplicates the currently selected channel, i.e creates a new channel of
the same type and with the identical measurement settings. The name of the new
channel is the same as the copied channel, extended by a consecutive number (e.g.
"IQAnalyzer" -> "IQAnalyzer 2").
The channel to be duplicated must be selected first using the INST:SEL command.
This command is not available if the MSRA/MSRT Master channel is selected.
Example:
INST:SEL 'IQAnalyzer'
INST:CRE:DUPL
Duplicates the channel named 'IQAnalyzer' and creates a new
channel named 'IQAnalyzer2'.
Usage: Event
Manual operation: See "Duplicate Current Channel" on page 126
INSTrument:CREate[:NEW] <ChannelType>, <ChannelName>
This command adds an additional measurement channel. You can configure up to 10
measurement channels at the same time (depending on available memory).
See also
●
INSTrument[:SELect] on page 828
●
INSTrument:DELete on page 825
Parameters:
<ChannelType> Channel type of the new channel.
For a list of available channel types see INSTrument:LIST?
on page 825.
<ChannelName> String containing the name of the channel.
Note that you can not assign an existing channel name to a new
channel; this will cause an error.
Selecting the Operating Mode and Application
