R&S FSW Series User Manual

Remote Commands
R&S
®
FSW
864User Manual 1173.9411.02 ─ 43
Parameters:
<Spacing> Range: 100 Hz to 2000 MHz
*RST: 14 kHz
Default unit: Hz
Manual operation: See "Adjacent Channel Spacings" on page 187
[SENSe:]POWer:ACHannel:SPACing:UALTernate<ch> <Spacing>
This command defines the distance from transmission channel to the upper alternate
channels.
For MSR signals, this command defines the distance from the CF of the last Tx chan-
nel in the last sub block to the upper alternate channel in asymmetrical configurations.
To configure the spacing for the lower alternate channel, use the [SENSe:]POWer:
ACHannel:SPACing:ALTernate<ch> command.
Suffix:
<ch>
.
1..n
Alternate channel number
Parameters:
<Spacing> Range: 100 Hz to 2000 MHz
*RST: 40 kHz (ALT1), 60 kHz (ALT2), 80 kHz (ALT3), ...
Default unit: Hz
Manual operation: See "Adjacent Channel Spacings" on page 187
[SENSe:]POWer:ACHannel:SSETup <State>
This command defines whether adjacent channels are defined symmetrically or not.
For more information see Chapter 7.2.3.4, "Measurement on Multi-Standard Radio
(MSR) Signals", on page 162.
Parameters:
<State> ON | OFF | 1 | 0
ON | 1
The upper and lower adjacent and alternate channels are
defined symmetrically. This is the default behaviour and corre-
sponds to the behavior in firmware versions before 2.10.
OFF | 0
The upper and lower channels can be configured differently.
*RST: 1
Manual operation: See "Symmetrical Adjacent Setup" on page 182
[SENSe:]POWer:ACHannel:BWIDth:UACHannel <Bandwidth>
[SENSe:]POWer:ACHannel:BANDwidth:UACHannel <Bandwidth>
This command defines the channel bandwidth of the upper adjacent channel in asym-
metrical configurations.
Configuring and Performing Measurements
