Remote Commands
R&S
®
FSW
883User Manual 1173.9411.02 ─ 43
Example:
SENS:POW:ACH:FILT:GAB:MAN:LOW BC,ON
Example: See "Example: Configuring and Performing an Asymmetrical
MSR ACLR Measurement" on page 895
Manual operation: See "Weighting Filters" on page 192
[SENSe:]POWer:ACHannel:FILTer[:STATe]:GAP<gap>:MANual:UPPer <SBGaps>,
<State>
[SENSe:]POWer:ACHannel:FILTer[:STATe]:GAP<gap>:MANual:UPPer? <SBGaps>
This command turns the weighting filter for the specified upper gap channel on and off.
Suffix:
<gap>
.
1 | 2
Gap channel number
Parameters:
<State> ON | OFF | 0 | 1
OFF | 0
Switches the function off
ON | 1
Switches the function on
*RST: 0
Parameters for setting and query:
<SBGaps> AB | BC | CD | DE | EF | FG | GH
Name of the gap, defined by the letters of the surrounding sub
blocks (e.g. "AB" for the gap between sub blocks A and B).
Example:
SENS:POW:ACH:FILT:GAP:MAN:UPP BC,ON
Example: See "Example: Configuring and Performing an Asymmetrical
MSR ACLR Measurement" on page 895
Manual operation: See "Weighting Filters" on page 192
[SENSe:]POWer:ACHannel:FILTer:ALPHa:GAP<gap>:MANual:LOWer <SBGaps>,
<Alpha>
[SENSe:]POWer:ACHannel:FILTer:ALPHa:GAP<gap>:MANual:LOWer? <SBGaps>
This command defines the roll-off factor for the specified lower gap channel's weighting
filter.
Suffix:
<gap>
.
1 | 2
Gap channel number
Parameters:
<Alpha> Roll-off factor
Range: 0 to 1
*RST: 0.22
