R&S FSW Series User Manual

Remote Commands
R&S
®
FSW
933User Manual 1173.9411.02 ─ 43
<ri> Selects the measurement range.
Parameters:
<SweepPoint> Minimum number of sweep points per range
Range: 1 to 32001
*RST: 1
Example:
SENSe1:ESPectrum:RANGe3:POINts:MIN:VALue 400
Manual operation: See "Min Sweep Points" on page 255
[SENSe:]ESPectrum<sb>:RANGe<ri>:MLCalc
<Function>
Defines the function used to calculate the limit line for the n-th power class for overlap-
ping ranges in Multi-SEM measurements. For details see "Limit calculation for individ-
ual ranges" on page 247.
Suffix:
<sb>
.
1 to 8
Sub block in a Multi-SEM measurement
<ri> 1..n
Selects the measurement range.
Parameters:
<Function> NONE | MAX | SUM
NONE
(reference ranges only:) the limit of the reference range is used;
Reference ranges always use the function "NONE".
SUM
sum of the two limit lines (calculated for linear powers) is used
MAX
maximum of the two limit lines is used
*RST: SUM (reference range: NONE)
Manual operation: See "Multi-Limit Calc <n>" on page 255
[SENSe:]ESPectrum<sb>:RANGe<ri>:RLEVel <RefLevel>
This command defines the reference level for a SEM range.
In case of high speed measurements, the reference level has to be identical for all
ranges.
Suffix:
<sb>
.
1 to 8
Sub block in a Multi-SEM measurement
<ri> 1..n
Selects the measurement range.
Configuring and Performing Measurements
