R&S FSW Series User Manual

Remote Commands
R&S
®
FSW
935User Manual 1173.9411.02 ─ 43
[SENSe:]ESPectrum<sb>:RANGe<ri>:TRANsducer <Transducer>
This command selects a transducer factor for a SEM range.
Note that
●
the transducer must cover at least the span of the range
●
the x-axis has to be linear
●
the unit has to be dB
Suffix:
<sb>
.
1 to 8
Sub block in a Multi-SEM measurement
<ri> 1..n
Selects the measurement range.
Parameters:
<Transducer> String containing the transducer file name, including the path
information.
Manual operation: See "Transducer Factor" on page 254
[SENSe:]ESPectrum<sb>:SSETup <State>
Enables or disables symmetrical configuration of the range settings.
See Chapter 7.6.4.1, "Ranges and Range Settings", on page 240.
Suffix:
<sb>
.
1 to 8
Sub block in a Multi-SEM measurement
Parameters:
<State> ON | OFF | 0 | 1
OFF | 0
Switches the function off
ON | 1
Switches the function on
*RST: 0
Manual operation: See "Symmetrical Setup" on page 256
14.5.7.5 Configuring the Reference Range
The following commands define the reference range for the SEM sweep list.
[SENSe:]ESPectrum<sb>:BWID......................................................................................936
[SENSe:]ESPectrum<sb>:FILTer[:RRC]:ALPHa.................................................................936
[SENSe:]ESPectrum<sb>:FILTer[:RRC][:STATe]................................................................936
[SENSe:]ESPectrum<sb>:RRANge?................................................................................936
[SENSe:]ESPectrum<sb>:RTYPe....................................................................................937
Configuring and Performing Measurements
