ROPA Maus 5 - Page 185

Operation
Folding the machine out/in
185 / 476
WARNUNG
Hazard of extremely severe injuries.
– Make sure, that nobody stands on the boarding platform.
– The driver is responsible for ensuring that there is nobody in the area between
safety rail at the boarding steps and cabin door when lifting or lowering the cabin.
– Raise driver's cabin up to the end-stop.
Raise/lower driver's cabin
Choose this function with R-Select.
+ key = raise driver's cabin
- key = lower driver's cabin
The driver's cabin may only be lowered or raised when the pickup side sections are
folded out.
– Swing the folding plates out.
Fold plates in/out
Choose this function with R-Select.
+ key = swing the folding plates out (fold up)
- key = swing the folding plates in (fold down)
When swinging up the fold plates, the support feet are simultaneously extended all the
way and both clearing shields are folded out.
