Operation
Folding the machine out/in
189 / 476
18a
(18a) Counterweight arm lock opened
18b
(18b) Counterweight arm lock at the
end-stop
18c
(18c) Counterweight arm lock closed
18a
18b
18c
ATTENTION
If the swivel arm is swiveled under the counterweight arm, then the lock (18a) of the
counterweight arm must be completely opened since, otherwise, machine damage
may occur.
