Operation
Folding the machine out/in
190 / 476
– Use the mini joystick (1) to swivel the counterweight arm somewhat out of the cen-
tral position.
1
DANGER
If a person is swept into the machinery during swiveling of the counterweight arm and
trapped, then this person may sustain fatal injuries!
– Staying under the counterweight arm when it is swung out is strictly prohibited.
– The machine operator must make sure that no people are located within the swivel-
ing range of the counterweight arm.
Danger of fatal injuries if the machine tips over.
– NEVER swivel the counterweight arm to the same side on which the truck con-
veyor is located.
– Specify loading direction.
Use the X-Y key (16) to select the loading direction (see page 139)
