Operation
Folding the machine out/in
205 / 476
– Lower the counterweight completely to the end-stop. To do so, select the function
"Lower counterweight" on the R-Select and press the key - for so long until the
counterweight is completely swung down. Look at the video monitor of the rear
view camera to make absolutely sure that the underrun protective device is com-
pletely swung down.
Counterweight up/down
Choose this function with R-Select.
+ key = raise counterweight
- key = lower counterweight
WARNUNG
Hazard of unwanted swiveling movements!
The machine may not be moved on roads or moved to another place if the counter-
weight and swivel arm are not locked.
The counterweight and swivel arms must always be locked when driving on public
roads.
The truck conveyor must be positioned on the transport support (see display (5) on
the R-Touch)!
5
5
5
