Operation
Folding the machine out/in
204 / 476
– Swivel the counterweight arm into the central position until the roller of the locking
lever rest is located on the lateral end-stop.
1
– Close the counterweight arm lock up to the end-stop. To do so, select the function
" Counterweight arm lock" on the R-Select, press and hold the key - until the lock
status display on the R-Touch displays the correct lock (18c).
18c
Counterweight arm lock closed
18c
