174
[Coding example 1]
Invokes 16 x 16 dots external character, Registration data in JIS HEX character
<A>
<KS>0
<KC>0
<T1>H21
00FF..........FF00
<Z>
<A>
<KS>0
<KC>0
<V>100<H>200<k1>H9021
<Q>2
<Z>
[Coding example 2]
Invokes 24 x 24 dots external character, Registration data in Shift JIS binary code
<A>
<KS>0
<KC>1
<T2>B<40>
16
<00FF..........FF00>
16
<Z>
<A>
<KS>0
<KC>1
<V>100<H>200<k2>B<F0>
16
<40>
16
<Q>2
<Z>
[Coding example 3]
Invokes 16 x 16 dots external character, Registration data in Unicode character
<A>
<KS>0
<KC>2
<T1>H01
00FF..........FF00
<Z>
<A>
<KS>0
<KC>2
<V>100<H>200<k1>HE001
<Q>2
<Z>
[Supplemental explanation]
• If the print out is not performed properly, register the data again.
• You cannot call the external characters registered as JIS/Shift JIS character as Unicode, and
vice versa.
• Valid data of registration code vary according to the Kanji set command <KS>.
