SATO CL6NX Programming Reference

708
Switching LAN and WLAN
This feature switches LAN and WLAN so that LAN can be used while the WLAN unit is connected.
Select the interface from Interface > Network > Interface on LCD.
There are 3 options to select from as below.
Item Description
AUTO LAN is enabled when LAN cable is connected at printer startup. WLAN
will be enabled if printer detects that it isn’t connected.
LAN Enables LAN and disables WLAN.
Wi-Fi Enables WLAN and disables LAN.
When the settings are changed, they will be enabled from the next time the printer restarts.
It is also possible to implement from DC2 command separately from LCD. (See Command
Specification document for details)
(Restrictions)
• The settings will automatically be switched to “AUTO” if you start up the printer after detaching
the WLAN unit with the settings set to “Wi-Fi”.
Parent topic LAN/Wireless LAN

SATO CL6NX Specifications

General

Flash memory	2000 MB
Storage media	Flash
Internal memory	256 MB
Built-in barcodes	Code 39, Code 93, Code-128 Codabar Library, EAN13, EAN8, GS1 DataBar, Industrial 2/5, Interleaved 2/5, Matrix 2/5
Internal storage capacity	2 GB
Cables included	AC
Maximum roll diameter	220 mm
Maximum printing width	167.5 mm
Printing media thickness	0.08 - 0.268 µm
USB port	Yes
USB connector	USB Type-A / USB Type-B
Bluetooth version	3.0
Serial interface type	RS-232C
USB 2.0 ports quantity	2
Connectivity technology	Wired & Wireless
Wi-Fi	No
Display type	LCD
Product color	Black
Display diagonal	3.5 \
Display resolution	320 x 240 pixels
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 80 %
Type	POS printer
Print speed	10 ips
Print technology	Direct thermal / Thermal transfer
Maximum resolution	203 x 203 DPI

Weight and Dimensions

Depth	457 mm
Width	338 mm
Height	321 mm
Weight	20000 g
