SATO CL6NX - Nfc; Basic Specification

739
NFC
Basic specification
Tag mode
Pass-through mode
Handover mode
Parent topic Part 2 Interface Specification
Basic specification
Interface standard
NFC forum Type 2 Tag compliant
Communication distance
Height from center of antenna is 0 mm: right and left ±5 mm to both right and left
Height from center of antenna is +10 mm: within the range of ±10 mm to both right and left
Interface
Enable/disable setting of communication behavior
Operation mode
Power OFF: Tag mode (Write NDEF format to NFC tag)
Power ON: Pass through mode, Bluetooth/Wi-Fi handover
Communication disconnection time-out
1 second
NFC receive buffer capacity
Tag mode: 888 bytes (Overall NFC tag memory)
Pass through mode: 51,200 bytes
* The maximum communication volume in pass through mode.
Ex) In pass through mode, communication volume at a time is 50 Kbytes or less. ("NG" is returned if
the communication volume is 50 Kbytes or more then receive data will be discarded)
