SATO CL6NX Programming Reference

670
Connector pin assignment
See below for the connector pin assignment of Centronics standard (compatible mode).
When IEEE1284 standard connector is used, connection complies with IEEE1284-B type connector.
Pin no. Signal name I/O Pin no. Signal name I/O
1 STROBE Input 19 STROBE-RETURN
2 DATA 1 Input 20 DATA 1-RETURN
3 DATA 2 Input 21 DATA 2-RETURN
4 DATA 3 Input 22 DATA 3-RETURN
5 DATA 4 Input 23 DATA 4-RETURN
6 DATA 5 Input 24 DATA 5-RETURN
7 DATA 6 Input 25 DATA 6-RETURN
8 DATA 7 Input 26 DATA 7-RETURN
9 DATA 8 Input 27 DATA 8-RETURN
10 ACK Output 28 ACK-RETURN
11 BUSY Output 29 BUSY-RETURN
12 PE Output 30 PE-RETURN
13 SELECT Output 31 INIT Input
14 AUTOFD Input 32 FAULT Output
15 33
16 LOGIC GND 34
17 CHASSIS GND 35
18 PERIPHERAL LOGIC HIGH Input 36 SELECTIN Input
Parent topic IEEE1284

SATO CL6NX Specifications

General

Flash memory	2000 MB
Storage media	Flash
Internal memory	256 MB
Built-in barcodes	Code 39, Code 93, Code-128 Codabar Library, EAN13, EAN8, GS1 DataBar, Industrial 2/5, Interleaved 2/5, Matrix 2/5
Internal storage capacity	2 GB
Cables included	AC
Maximum roll diameter	220 mm
Maximum printing width	167.5 mm
Printing media thickness	0.08 - 0.268 µm
USB port	Yes
USB connector	USB Type-A / USB Type-B
Bluetooth version	3.0
Serial interface type	RS-232C
USB 2.0 ports quantity	2
Connectivity technology	Wired & Wireless
Wi-Fi	No
Display type	LCD
Product color	Black
Display diagonal	3.5 \
Display resolution	320 x 240 pixels
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 80 %
Type	POS printer
Print speed	10 ips
Print technology	Direct thermal / Thermal transfer
Maximum resolution	203 x 203 DPI

Weight and Dimensions

Depth	457 mm
Width	338 mm
Height	321 mm
Weight	20000 g
