54
[ESC+&] Store Form Overlay
ESC & ParameterHexadecimal code
<1B>
16
<26>
16
(aab
～
b)
Initial value Nil
When the power is OFF The set command is not maintained.
Valid range within item The set parameter is valid until the next valid setting.
Valid range and term of
command
Valid range between items The set parameter is valid until the next valid setting.
[Function]
Specifying the registration of form overlay.
[Format]
<&>(aab
～
b)
• Parameter
a [Registration key] = Valid range : 01 to 99 (omissible)
b [Comment] = Max. 16 bytes (omissible)
[Coding Example]
<A>
<V>100<H>50<FW>1010V800H750
<V>100<H>50<FW>0505V760H710
<V>100<H>50<XB>0MODEL
<&>01DATA1
<Z>
[Supplementary Explanation]
• This command saves fixed print contents to the printer and then, Recall Form Overlay </>
combines the contents with drawing of general data to print out.
• Specify this command at the end of data string that is to be stored. Drawing valid range in form
overlay registration is same as printing area.
• This command can register only one format. Use any code from 01 to 99 as a registration key.
• To change contents, specify Clear Form Overlay (<*>&), and then register new storage data.
• Invoke registered contents by Recall Form Overlay </>.
•
When specifying Media Size <A1>, it will be extracted in the specified area.
