SATO CL6NX Programming Reference

617
Part 2 Interface Specification
Overview
Communication protocol
RS-232C
IEEE1284
USB
LAN/Wireless LAN
Bluetooth
External signal interface
USB HOST
NFC
Notes about the Interface
Overview
Overview
Combination of interface
Parent topic Part 2 Interface Specification
Overview
This printer has a build-in interface on the printer to communicate data with host and has an external
signal interface to connect printer and peripheral devices.
Followings are the types of build-in interface.
• USB interface (USB2.0 High-speed, A type connector/B type connector)
• LAN interface (10BASE-T/100BASE-TX automatic switch, RJ45 connector)
• RS-232C interface (DB9 pin (female))
• IEEE1284 interface (Communication mode: ECP/compatible, Amphenol 36 pin)
• External signal interface (Amphenol 14 pin)
• Bluetooth interface (Ver. 3.0+EDR Class2)
• NFC interface
In addition, following type of interface is available as option.
• Wireless LAN unit (802.11a/b/g/n)
Parent topic Overview

SATO CL6NX Specifications

General

Flash memory	2000 MB
Storage media	Flash
Internal memory	256 MB
Built-in barcodes	Code 39, Code 93, Code-128 Codabar Library, EAN13, EAN8, GS1 DataBar, Industrial 2/5, Interleaved 2/5, Matrix 2/5
Internal storage capacity	2 GB
Cables included	AC
Maximum roll diameter	220 mm
Maximum printing width	167.5 mm
Printing media thickness	0.08 - 0.268 µm
USB port	Yes
USB connector	USB Type-A / USB Type-B
Bluetooth version	3.0
Serial interface type	RS-232C
USB 2.0 ports quantity	2
Connectivity technology	Wired & Wireless
Wi-Fi	No
Display type	LCD
Product color	Black
Display diagonal	3.5 \
Display resolution	320 x 240 pixels
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 80 %
Type	POS printer
Print speed	10 ips
Print technology	Direct thermal / Thermal transfer
Maximum resolution	203 x 203 DPI

Weight and Dimensions

Depth	457 mm
Width	338 mm
Height	321 mm
Weight	20000 g
