Modification Command
[ESC+P] Character Pitch
[ESC+L] Enlargement
[ESC+PS] Proportional Pitch
[ESC+PR] Release Proportional Pitch
[ESC+%] Rotation
[ESC+F] Sequential number
[ESC+FW] Ruled / Grid Line Print
[ESC+FC] Print Circle
[ESC+FT] Print Triangle
[ESC+(] Reverse Color Print
[ESC+KC] Kanji Code
[ESC+&] Store Form Overlay
[ESC+/] Recall Form Overlay
[ESC+0] Partial Edit
[ESC+WD] Partial Copy
[ESC+J] Journal Print
[ESC+RF] Recall Font & Logo
[ESC+RM] Mirror Image
[ESC+KS] Kanji Set
[ESC+AL] Field alignment
Parent topic Part 1 SBPL Commands
[ESC+P] Character Pitch
ESC P ParameterHexadecimal code
<1B>
16
<50>
16
aa
Initial value aa=02
When the power is OFF The set parameter is not maintained.
Valid range within items The set parameter is valid until the next valid setting.
Valid range and term of
command
Valid range between items The set parameter becomes initial value at the next item
<A>.
[Function]
Specifying character pitch by dot.
[Format]
<P>aa
• Parameter
a [Character pitch] = Valid range: 00 to 99 dots
[Coding Example]
Character pitch: 10
<A>
<V>200<H>100<P>10<L>0202<XM>ABCD
<Q>2
<Z>
[Supplementary Explanation]
• Character pitch means the character gap or font gap when selecting font or barcode.
• Specified character pitch will be widened based on the ratio of Enlargement <L>.
• Even if linefeed code [CR] is specified in Auto Linefeed <E>, the character pitch remains the
same without returning to initial value. Start of Data Transmission <A> can be used to reset to
the initial value.
• By specifying Character Pitch <P> just before the barcode specification, pitch command
becomes valid for barcode module.
Object barcode: NW-7, CODE39, Industrial 2of5, Matrix 2of5
For more information, see (3) Intercharacter gap in [Barcode Command].
• Data specification except numeric value or specification of over-digit will give the initial value.
