207
[ESC+BP] Postnet
ESC BP ParameterHexadecimal code
<1B>
16
<42>
16
<50>
16
n...n
Initial value Nil
When the power is OFF The set parameter is not maintained.
Valid range within items The set parameter becomes invalid.
Valid range and term of
command
Valid range between items The set parameter becomes invalid.
[Function]
Specifying POSTNET barcode.
[Format]
<BP>n...n
• Parameter
n = Print data (Refer to the POSTNET Code Table)
Note that the digits other than specified below are not allowed.
- 5 digits (POSTNET-32 format)
- 6 digits (POSTNET-37 format)
- 9 digits (POSTNET-52 format)
- 11 digits (POSTNET-62 Delivery Point format)
[Coding Example]
Postal code: 11 digits: 01234567890
<A>
<V>100<H>200<BP>01234567890
<Q>2
<Z>
[Supplementary Explanation]
• If specifying the value other than 5, 6, 9, and 11 digits for print data, it will be ignored.
• Only numeric can be specified as print data.
To Next Page
