411
[ESC+IP0] EPC code write (UHF M6e) (CL4NX Only)
Command ESC IP0 Parameter
Hexadecimal code <1B>
16
<49>
16
<50>
16
<30>
16
See under “Parameters”.
Initial Value Nil
When turning off the power The set command is not maintained.
Valid range within item The set parameter becomes invalid.
Valid range and term of
command
Valid range between items The set parameter becomes invalid.
[Function]
This command writes the EPC code and other data to the EPC corresponding RFID tag. The
standard format (three-character parameter identifier) is used when using the memory area
extended for each IC chip manufacturer.
Available in M6e module installed printers.
[Format]
[Standard format]
<IP0>e:h(,pcw:xxx)(,epc:xxxx…xxxx)(,usr:xxxx…xxxx)|(,usa:dddd,aaaaa…aaaa)(,lck:bbbbb);
[Conventional format]
[SSCC96 code conversion]
<IP0>e:a,c:d,s:d,d:ddddddddddddd(,o:xxx)(,m:bbbbb)(,k:xxxxxxxx)(,a:xxxxxxxx)(,p:xxxxxxxx);
[SGTIN96 encoding]
<IP0>e:c,f:d,c:d,t:d,d:ddddddddddddddddd,n:dddddddddddd(,o:xxx)(,m:bbbbb)(,k:xxxxxxxx)(,a:xxxxxxxx)
(,p:xxxxxxxx);
[Free mapping]
<IP0>e:z(,d:xxxxxxxxxxxxxxxxxxxxxxxx)(,u:xxxxxxxxxxxxxxxx)(,k:xxxxxxxx)(,a:xxxxxxxx)
(,p:xxxxxxxx)(,o:xxx)(,m:bbbbb)(,k:xxxxxxxx)(,a:xxxxxxxx)(,p:xxxxxxxx);
* Typical parameters are shown in the format examples above. Refer to the next item for details on
the parameters.
[Conventional format] is solely for maintaining compatibility with models before CL4NX. For
commands newly created for the CL4NX and later models, please create with the [Standard Format].
• Parameter
EPC encode type parameter
e: EPC encode
Type
Specify the parameter right after <IP0>.
The parameter cannot be omitted.
h [Standard format]
Use the three-character parameter
identifier after the declaration.
The memory area extended for each IC
chip manufacturer can be extended for
other than the standard Gen 2 tag.
To Next Page
