SATO CL6NX - [DC2+PB] Printer Setting Information Acquisition

544
[DC2+PB] Printer setting information acquisition
Command DC2 PB Parameter
Hexadecimal code <12>
16
<50>
16
<42>
16
(,aa(,b...b)) + EOT(04h)
Initial Value None
When turning off the power -
Valid range -
Printer operation in
progress
The command can be received even during the printer
operation.
When acquiring label
sensor information
Commands are not accepted while acquiring sensor
information. ([NAK] reply)
Valid range and term of
command
Error The command can be received even if an error is
occurring.
[Function]
This command is used to acquire the printer information.
[Format]
[DC2]PB(,aa(,b...b))[EOT]
[Parameters]
Symbol Parameter name Valid range Note
a Identifier Refer to [Identifier] below When omitted, all items will be
returned.
b Setting Item name Refer to [DC2 + PA]
command
Acquire up to [EOT]
[Return data format (normal)]
[STX]a...a,bb,c...c,d...d(,ee,f...f,g...g)...[ETX]
[Return data]
Symbol Parameter name Valid range
a Total number of data byte
* This is the total number of bytes after parameter
b. The delimiting comma between parameters a
and b, and the ETX are not included.
Data size from the first identifier until before
[ETX]
b(e) Identifier Refer to [Identifier] below.
c(f) Setting information data size
* Number of bytes of the section unit after
parameter d. The delimiting comma between
sections is not included.
Size of the corresponding setting information
data
d(g) Setting information data
* Text format
Refer to "Setup information data" below.
