SATO CL6NX Programming Reference

325
System Command
[ESC+CS] Print Speed
[ESC+#F] Print Darkness
[ESC+#E] Print Darkness (Compatible command)
[ESC+A1] Media Size
[ESC+A3] Base Reference Point
[ESC+EP] Print End Position
[ESC+~] Multiple Cut
[ESC+CT] Cut Number Unit
[ESC+NC] Eject and Cut
[ESC+~A] Cut Number Unit
[ESC+~B] Eject and Cut
[ESC+*] Memory Clear
[ESC+@] Offline
[ESC+C] Reprint
[ESC+E] Auto Line Feed
[ESC+PO] Offset
[ESC+IG] Sensor Type
[ESC+PH] Print Method
[ESC+PM] Print mode
[ESC+KM] Mincho (Kanji)
[ESC+KG] Gothic (Kanji)
[ESC+CE] European code page
[ESC+TK] Forced Tear Off
[ESC+TW] Option Waiting Time
[ESC+CL] Delete CR/LF
[ESC+VB] Barcode Checker
[ESC+#] Base Reference Point (CL4NX Only)
Parent topic Part 1 SBPL Commands
[ESC+CS] Print Speed
ESC CS ParameterHexadecimal code
<1B>
16
<43>
16
<53>
16
aa
Initial value Refer to the table below.
When the power is OFF The set parameter is maintained.
Valid range within items The set parameter is valid until the next valid setting.
Valid range and term of
command
Valid range between items The set parameter is valid until the next valid setting.
[Function]
Specifying the speed of printing.
[Format]
<CS>aa
• Parameter
a [Print speed] = Refer to the table below.
[Coding Example]
<A>
<CS>4
<Z>
[Supplementary Explanation]
• Print speed value specified by the command or LCD is maintained.
[Notes]
• If the value over valid range is specified, command error will occur and print speed will not be
changed.
• Use default set operation of the printer to set back the value to the initial one.
• If print mode is linerless cutter, the maximum speed would be 6 inches/sec and initial value
would be 4 inches/sec. Command error does not occur if 7 inches/sec to maximum for each
model has been specified. In that case the value will not be set.
• If print mode is dispenser, the maximum speed would be 10 inches/sec. Command error does
not occur if 11 inches/sec to maximum for each model has been specified. In that case the value
will not be set.

SATO CL6NX Specifications

General

Flash memory	2000 MB
Storage media	Flash
Internal memory	256 MB
Built-in barcodes	Code 39, Code 93, Code-128 Codabar Library, EAN13, EAN8, GS1 DataBar, Industrial 2/5, Interleaved 2/5, Matrix 2/5
Internal storage capacity	2 GB
Cables included	AC
Maximum roll diameter	220 mm
Maximum printing width	167.5 mm
Printing media thickness	0.08 - 0.268 µm
USB port	Yes
USB connector	USB Type-A / USB Type-B
Bluetooth version	3.0
Serial interface type	RS-232C
USB 2.0 ports quantity	2
Connectivity technology	Wired & Wireless
Wi-Fi	No
Display type	LCD
Product color	Black
Display diagonal	3.5 \
Display resolution	320 x 240 pixels
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 80 %
Type	POS printer
Print speed	10 ips
Print technology	Direct thermal / Thermal transfer
Maximum resolution	203 x 203 DPI

Weight and Dimensions

Depth	457 mm
Width	338 mm
Height	321 mm
Weight	20000 g
