SATO CL6NX Programming Reference

326
[Parameter Initial Value and Specified Range]
Model Head density Initial
value [aa]
Parameter
Valid Range
Print speed corresponding
to parameter
203 dpi 6 2, 3, 4, 5, 6, 7, 8, 9,
10
305 dpi 6 2, 3, 4, 5, 6, 7, 8
CL4NX
609 dpi 4 2, 3, 4, 5, 6
203 dpi 6 2, 3, 4, 5, 6, 7, 8, 9,
10
CL6NX
305 dpi 6 2, 3, 4, 5, 6, 7, 8
2: 2 (inch/s) 50.8 (mm/s)
3: 3 (inch/s) 76.2 (mm/s)
4: 4 (inch/s) 101.6 (mm/s)
5: 5 (inch/s) 127.0 (mm/s)
6: 6 (inch/s) 152.4 (mm/s)
7: 7 (inch/s) 177.8 (mm/s)
8: 8 (inch/s) 203.2 (mm/s)
9: 9 (inch/s) 228.6 (mm/s)
10: 10 (inch/s) 254.0 (mm/s)
Parent topic System Command

SATO CL6NX Specifications

General

Flash memory	2000 MB
Storage media	Flash
Internal memory	256 MB
Built-in barcodes	Code 39, Code 93, Code-128 Codabar Library, EAN13, EAN8, GS1 DataBar, Industrial 2/5, Interleaved 2/5, Matrix 2/5
Internal storage capacity	2 GB
Cables included	AC
Maximum roll diameter	220 mm
Maximum printing width	167.5 mm
Printing media thickness	0.08 - 0.268 µm
USB port	Yes
USB connector	USB Type-A / USB Type-B
Bluetooth version	3.0
Serial interface type	RS-232C
USB 2.0 ports quantity	2
Connectivity technology	Wired & Wireless
Wi-Fi	No
Display type	LCD
Product color	Black
Display diagonal	3.5 \
Display resolution	320 x 240 pixels
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 80 %
Type	POS printer
Print speed	10 ips
Print technology	Direct thermal / Thermal transfer
Maximum resolution	203 x 203 DPI

Weight and Dimensions

Depth	457 mm
Width	338 mm
Height	321 mm
Weight	20000 g
