Return status of Status 4
This communication protocol is used to return the condition of this product and reply as a status to
the host by receiving four types of request commands and print commands.
The following describes about commands and return status.
1) Status request command
This command returns the job ID number of receiving data in printing, the status of this product,
the number of remaining label to print, and job name to host. All "0" (HEX 30H) is returned for print
quality when the print is completed or when there is no received data. A "space" (HEX 20H) is
returned for the job ID when Job ID Number <ID> is not specified.
Please do not send ENQ (Status request) while sending print data (STX <A> to <Z> ETX). Status
would not be returned properly or print would not be performed properly if ENQ is sent.
1. Command ENQ (HEX 05H)
2. Return status, Format
LAN, Wireless LAN 36 bytes LAN
Legacy Status setting is valid.
Number of
transmission bytes
4 bytes
00000020H
The ID no. specified with Job ID
specification command is set.
The print job name specified with JOB
name specification command is set.
000000 through 999999
Number of
transmission bytes
4 bytes
0000001CH
ENQ
1 byte
05H
STX
1 byte
02H
IDNo.
2 bytes
Status
1 byte
JOBname
16 bytes
ETX
1 byte
03H
LAN, WLAN
32 bytes
Legacy Status for Port9100 Disable
STX
1 byte
02H
ID no.
2 bytes
Status
1 byte
Remaining no.
of labels
6 bytes
JOB name
16 bytes
ETX
1 byte
03H
Interface other than
the above
27 bytes
Number of
transmission bytes
4 bytes
0000001CH
ENQ
1 byte
05H
STX
1 byte
02H
IDNo.
2 bytes
Status
1 byte
No. of
Remaining
labels
JOB name
16 bytes
ETX
1 byte
03H
No. of
Remaining
labels
6 bytes
6 bytes
3. Return status list
Description ASCII HEX
NO ERROR 0 30
RIBBON/LABEL NEAR END 1 31
BUFFER NEAR FULL 2 32
RIBBON/LABEL NEAR END & BUFFER NEAR FULL 3 33
PRINT HALT (NO ERROR) 4 34
(UNUSED) BATTERY NEAR END 5 35
(UNUSED) BATTERY NEAR END & RIBBON NEAR END 6 36
(UNUSED) BATTERY NEAR END & BUFFER NEAR FULL 7 37
OFFLINE
STATE
(UNUSED) BATTERY NEAR END & RIBBON NEAR END &
BUFFER NEAR FULL
8 38
NO ERROR A 41ONLINE
STATE
WAIT TO
RECEIVE
RIBBON/LABEL NEAR END B 42

SATO CL6NX Specifications

General

Flash memory	2000 MB
Storage media	Flash
Internal memory	256 MB
Built-in barcodes	Code 39, Code 93, Code-128 Codabar Library, EAN13, EAN8, GS1 DataBar, Industrial 2/5, Interleaved 2/5, Matrix 2/5
Internal storage capacity	2 GB
Cables included	AC
Maximum roll diameter	220 mm
Maximum printing width	167.5 mm
Printing media thickness	0.08 - 0.268 µm
USB port	Yes
USB connector	USB Type-A / USB Type-B
Bluetooth version	3.0
Serial interface type	RS-232C
USB 2.0 ports quantity	2
Connectivity technology	Wired & Wireless
Wi-Fi	No
Display type	LCD
Product color	Black
Display diagonal	3.5 \
Display resolution	320 x 240 pixels
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 80 %
Type	POS printer
Print speed	10 ips
Print technology	Direct thermal / Thermal transfer
Maximum resolution	203 x 203 DPI

Weight and Dimensions

Depth	457 mm
Width	338 mm
Height	321 mm
Weight	20000 g
