SATO CL6NX Programming Reference

316
[ESC+DC] DataMatrix (ECC200) Data Specify (Compatible
command)
ESC DC ParameterHexadecimal code
<1B>
16
<44>
16
<43>
16
n...n
Initial value Nil
When the power is OFF The set parameter is not maintained.
Valid range within items The set parameter becomes invalid.
Valid range and term of
command
Valid range between
items
The set parameter becomes invalid.
[Function]
Specifying data for DataMatrix (ECC200).
[Format] (Data specification part)
<DC>n...n
• Parameter
n [Print data] = Data
[Coding Example]
Cell width: 02, Cell pitch: 02, Number of cells per line: 000 (Auto setup), Number of cell lines: 000
(Auto setup), Print data: 1234567890
<A>
<V>100<H>200
<BX>01200202000000001
<DC>1234567890
<Q>2
<Z>
[Supplementary Explanation]
• DataMatrix (ECC200) can specify from 00H to FFH except for printer control code of 05H, 10H,
11H, 18H, 1BH. When specifying control code for data, use DataMatrix<2D50>.
Data format Number of data
Numeric 3116
Alphanumeric 2335
Data format
Binary (00H to FFH) 1556
* Value in above table shows the maximum number of data that can be specified as barcode data.
[Precautions during use]
• This is the command of the old specification. Recommend the use of <2D50>.
Parent topic 2D Code
