Wireless LAN settings
802.1x authentication and certification
Parent topic LAN/Wireless LAN
802.1x authentication and certification
Depending on format, certification may be required or may not be required for 802.1x authentication.
When certification is required, it is necessary to import it from Web setting screen or USB memory.
Following shows the necessity of certifications, ID and password of each format for 802.1
authentication followed by the types of certifications and secret keys.
■ Items to be imported from Web setting screen and USB memory
No. Items to be imported Description
1 Root certificate File: Select a file of root certificate
2 Client certificate Password: Enter secret password of client certificate
File: File of client certificate
3 Secret key Password: Enter password of secret key
File: Select file of secret key
4 PAC file Password: Enter password of PAC file
File: Select PAC file.
■ Necessity of ID/Password, certifications of each format for 802.1x authentication
Necessary information (○: Necessary, ×: Unnecessary)EAP
format
User name Password Certification
Password
Root
certificate
Client
certificate
Secret key PAC file
EAP-TLS ○ × ○ ○ ○ ○ ×
EAP-PEAP ○ ○ × ○ × × ×
EAP-LEAP ○ ○ × × × × ×
EAP-TTLS ○ ○ × ○ × × ×
EAP-FAST ○ ○ × × × × ○
