[ESC+GT] BMP File Registration
ESC GT ParameterHexadecimal code
<1B>
16
<47>
16
<54>
16
aaa,bbbbb,n...n
Initial Value Nil
When the power is OFF The set parameter is not maintained.
Valid range within items The set parameter becomes invalid.
Valid range and term of
command
Valid range between items The set parameter becomes invalid.
[Function]
Specifying the registration of BMP file created by such as Image editing application.
[Format]
<GT>aaa,bbbbb,n...n
Parameter
a [Registration number]
Valid Range : 1 to 999
b [Total bytes of BMP file]
Valid Range : 1 to 99999
Specify the file size of BMP file for total bytes.
n [Data] = BMP file data
Data is sent as binary data (Outputs 8 bits as one character data all at once)
[Coding Example]
<A>
<CC>1
<GT>1,12345,<424D00~00>
16
<Z>
[Supplementary Explanation]
Specify the card slot number used for Card Slot <CC> prior to this command <GT> by all
means.
Data is sent as binary data (Outputs 8 bits as one character data all at once). In this case, file
size of BMP file becomes the total bytes, and BMP file data becomes data.
When [Total bytes of BMP file] is not matching the transfer data, this may cause malfunction.
Total bytes are the file size displayed at [Property] and such.
BMP file is available in Black/White mode only. In color mode, printing will not be performed due
to command error.
Also, this command is not valid for BMP compressed file. Make sure that the file extension is set
to [BMP] before printing.
The error occurs when unused or the slot which this product is allocated is specified.
[Note]
Do not turn the printer's power off when accessing to the memory. When the printer power is off
while memory accessing, the data in the accessed media may be corrupted.
Parent topic Memory Card Command
