SATO CL6NX Programming Reference

659
Status4 return
This communication protocol is designed for the purpose of monitoring printer status in the host, and
returns Status from the printer by receiving request command from the host.
Status is returned immediately after receiving request command.
In this protocol, receive mode is set to multiple buffer.
Connection diagram
I/O signal
Timing chart
Parent topic RS-232C
Connection diagram
1)DB
-
9P
Printer
Host
RD
2
3
SD
SD
3
2
RD
SG
5
5
SG
IMPORTANT: Depending on the host used, it may need to loop CS and RS (constantly maintain at
“High” level) on the host side. For more details, refer to your host computer documentation.
Parent topic Status4 return
I/O signal
Pin No. Signal I/O Description
2 RD Input Data transferred from the host to the printer
3 SD Output Data transferred from the printer to the host
5 SG - Signal ground
Parent topic Status4 return

SATO CL6NX Specifications

General

Flash memory	2000 MB
Storage media	Flash
Internal memory	256 MB
Built-in barcodes	Code 39, Code 93, Code-128 Codabar Library, EAN13, EAN8, GS1 DataBar, Industrial 2/5, Interleaved 2/5, Matrix 2/5
Internal storage capacity	2 GB
Cables included	AC
Maximum roll diameter	220 mm
Maximum printing width	167.5 mm
Printing media thickness	0.08 - 0.268 µm
USB port	Yes
USB connector	USB Type-A / USB Type-B
Bluetooth version	3.0
Serial interface type	RS-232C
USB 2.0 ports quantity	2
Connectivity technology	Wired & Wireless
Wi-Fi	No
Display type	LCD
Product color	Black
Display diagonal	3.5 \
Display resolution	320 x 240 pixels
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 80 %
Type	POS printer
Print speed	10 ips
Print technology	Direct thermal / Thermal transfer
Maximum resolution	203 x 203 DPI

Weight and Dimensions

Depth	457 mm
Width	338 mm
Height	321 mm
Weight	20000 g
