[ESC+&S] Form Overlay Registration
ESC &S ParameterHexadecimal code
<1B>
16
<26>
16
<53>
16
,aa(,bbbb,ccccc)
Initial value Nil
When the power is OFF The registered data becomes valid.
Valid range within items The registered data is valid until the next specification is
made.
Valid range and term of
command
Valid range between items The registered data is valid until the next specification is
made.
[Function]
Specifying the registration of fixed print contents to a memory card.
[Format]
<&S>,aa(,bbbb,ccccc)
• Parameter
a [Registration No.] = Valid range: 1 to 99
b [Size specification of window width] = Valid range: Refer to the table below (omissible).
c [Size specification of window height] = Valid range: Refer to the table below (omissible).
[Coding Example]
<A>
<V>100<H>100<X21>,MODEL
<CC>1
<&S>,1
<Z>
[Supplementary Explanation]
• Specify slot No. with Card Slot for Use <CC> prior to this command <&S> by all means.
• Delimit Start of Data Transmission <A> and End of Data Transmission <Z> with the format to be
registered.
• Registration of identical registration No. is invalid.
• Both Print of Graphic <G> and Print of BMP File <GM> can be registered.
• This command <&S> allows up to 99 registries. Note that the capacity of registry may vary
depending on the memory card to be used.
• Data registered with this command <&S> can be cleared with Clear <*>R.
• The error occurs when specifying unused or specifying the slot which the printer is allocated.
[Note]
• Do not turn the printer's power off when accessing to the memory. When the printer power is off
while memory accessing, the data in the accessed media may be corrupted.
