377
[Valid Range]
Model Head density Horizontal size of the window
Valid Range (dots)
Vertical size of the window
Valid Range (dots)
203 dpi 50 to 832 50 to 20000
305 dpi 50 to 1248 50 to 18000
CL4NX
609 dpi 50 to 2496 50 to 9600
203 dpi
50 to 1216
*1
50 to 1340
*2
50 to 20000CL6NX
305 dpi
50 to 1984
*1
50 to 2010
*2
50 to 18000
*1 Valid range when “Head Base Position” is set to “Standard”.
*2 Valid range when “Head Base Position” is set to “Left-justify”.
[Valid Commands]
Print position <V> <H>
<XU> <XS> <XM> <XB> <XL> <OA> <OB> <RD> <$=> <K1>
<K2> <K3> <K4> <K5> <K8> <K9> <KA> <KB> <KD> <k1>
<k2> <k3> <k4> <k5> <k8> <k9> <kA> <kB> <kD> <U>
Font
<S> <M> <WB> <WL> <X20> <X21> <X22> <X23> <X24>
<B> <BC> <BG> <BI> <D> <D><d> <BD> <BT> <BW> <BP>Barcode
<BF> <BS> <BL> <BL><d> <BM>
<2D10> <BK> <2D12> <2D20> <BV> <2D30> <2D31> <2D32> <BQ>
2D Code
<2D50> <BX> <2D51> <2D70>
Composite
symbol
<EU>
Modification <WD> <FW> <(> <RF> <FC> <FT> <RM>
Graphic <G> <GM> <GP>
In general, this command is used for [Registration number] only. Specification of window height and
width will control the movement with Vertical Print Position <V> and Horizontal Print Position <H> at
the time of calling. For the movement at the time of calling, if registered area is exceeding print area,
the portion outside of print area will not be printed.
To Next Page
