SATO CL6NX - Timing Chart

660
Timing chart
1) Normal process
2) Cancel process
Note: Avoid sending ENQ while sending the print data (STX <A> - <Z> ETX).
This may cause return status error or print error.
Printing (1)
Printing (2)
Power On
Printer
RD
SD
Initializing
Printing (1)
Online
Receive buffer near full state Receive buffer near full release
STX.ETX (2)
Offline
Receive/Analysis/Edit (2)
Printing (2)
Printer Status
Press the LINE
button Press the LINE
button
Receive/Analysis/Edit (1)
STX..ETX (1)
STX.ETX (3)
Receive/Analysis/Edit (3)
Status Status
Status
Status
Status
Printer
RD
SD
Online
Receive/Analysis/Edit (2)
Receive/Analysis/Edit (1)
STX..ETX (1) STX..ETX (2)
Status Status
Status
500 msec
Status
