[ESC+TU] Printing tag data (UHF M6e) (CL4NX Only)
Command ESC TU Parameter
Hexadecimal code <1B>
16
<54>
16
<55>
16
a (,bbcccdddn ~ n)
Initial Value Nil
When turning off the power The set command is not maintained.
Valid range within item The set parameter is valid until the next valid setting.
Valid range and term of
command
Valid range between items The set parameter becomes invalid.
[Function]
Reads data from RFID tag and develops to specified direction to make it possible to print on label.
[Format]
<TU>a (,bbcccdddn
n)
Parameters
a = To use this functionality or not

1: Read data and start using

0: Cancel use
bb = Block number
     01:
EPC area
     02:
TID area
     03:
USER area
ccc = Start address of memory (HEX)
ddd = End address of memory (HEX)
The amount of information per one address is 2 bytes(4 characters) in case of Gen2.
An RFID tag error occurs if you specify an address that exceeds tag capacity.
The difference between “Start address of memory” and “End address of memory” shall be kept
within 7 because the maximum amount of read data is 32 characters.
n = Specify ID. Specify any string within 4 to 16 characters to be used for assigning data.
(All parameters should be in the ASCII format)
[Coding Sample1]
A sample specifying 32 digits from start address 00 to end address 07 in EPC area of Gen2 tag,
using SATO as ID. (Amount of information per 1 address: 4 characters)
<A>
<TU>1,01000007SATO
<%>0
<V>0410
<H>0090
<P>00
<L>0101
<XM>SATO
<%>0
<V>0060
<H>0040
<D>102120*SATO*
<%>0
<V>0195
<H>0055
<P>00
<L>0101
