SATO CL6NX Programming Reference

621
Return status
The purpose of return status is to manage the status of this product from the host, and the product
returns the status by request command from host.
There are three types of return status format, Status 3, Status 4, and Status 5. Each return status is
listed below.
The product returns the status after receiving request command.
Communication
protocol
Command Command name Remarks
READY/BUSY
－ －
XON/XOFF
－ －
ENQ Status request command Status 3
CAN Cancel request command
ENQ Status request command
CAN Cancel request command
DLE Print end request
command
Status 4
DC1 Print start request
command
SOH + ENQ Status request command
SOH + CAN Cancel request command
SOH + DLE Print end request
command
Status 5
SOH + DC1 Print start request
command
* In status 3 and 4, the printer processes the command for ESC+ENQ and ESC+CAN and then returns the
status, however, for ESC+DLE and ESC+DC1, the printer neither processes the command, nor returns the
status.
Remarks
When you acquire return status from this product, please input transmission interval time after
sending each command to printer.
Command Command name Transmission interval
time (Actual value)
ENQ (05H) Status request 5 ms or more
* 300 ms or more for Wireless LAN
CAN (18H) Cancel request
DLE (10H) Print end request
DC1 (11H) Print start request
500 ms or more

SATO CL6NX Specifications

General

Flash memory	2000 MB
Storage media	Flash
Internal memory	256 MB
Built-in barcodes	Code 39, Code 93, Code-128 Codabar Library, EAN13, EAN8, GS1 DataBar, Industrial 2/5, Interleaved 2/5, Matrix 2/5
Internal storage capacity	2 GB
Cables included	AC
Maximum roll diameter	220 mm
Maximum printing width	167.5 mm
Printing media thickness	0.08 - 0.268 µm
USB port	Yes
USB connector	USB Type-A / USB Type-B
Bluetooth version	3.0
Serial interface type	RS-232C
USB 2.0 ports quantity	2
Connectivity technology	Wired & Wireless
Wi-Fi	No
Display type	LCD
Product color	Black
Display diagonal	3.5 \
Display resolution	320 x 240 pixels
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 80 %
Type	POS printer
Print speed	10 ips
Print technology	Direct thermal / Thermal transfer
Maximum resolution	203 x 203 DPI

Weight and Dimensions

Depth	457 mm
Width	338 mm
Height	321 mm
Weight	20000 g
