SATO CL6NX Programming Reference

225
2D Code
[ESC+2D10] PDF417
[ESC+2D12] Micro PDF417
[ESC+2D20] MaxiCode
[ESC+2D30] QR Code (Model 2)
[ESC+2D31] QR Code (Model 1)
[ESC+2D32] Micro QR Code
[ESC+2D50] DataMatrix (ECC200)
[ESC+2D51] GS1 DataMatrix
[ESC+2D70] Aztec Code
[ESC+BQ] QR Code (Compatible command)
[ESC+BV] MaxiCode (Compatible command)
[ESC+BK] PDF417 (Compatible command)
[ESC+BX] DataMatrix (ECC200) (Compatible command)
[ESC+DC] DataMatrix (ECC200) Data Specify (Compatible command)
[ESC+FX] DataMatrix (ECC200) Sequential Number (Compatible command)
[ESC+QV] QR code version
Parent topic Part 1 SBPL Commands
[ESC+2D10] PDF417
ESC 2D10 ParameterHexadecimal code
<1B>
16
<32>
16
<44>
16
<31>
16
<30>
16
,aa,bb,c,dd,ee(,f)
Initial value Nil
When the power is OFF The set parameter is not maintained.
Valid range within items The set parameter becomes invalid.
Valid range and term of
command
Valid range between items The set parameter becomes invalid.
[Function]
Specifying PDF417.
[Format](Setting part)
<2D10>,aa,bb,c,dd,ee(,f)
• Parameter
a [Minimum module width] = Valid Range : 01 to 27 dots
b [Minimum module height] = Valid Range : 01 to 72 dots
c [Security level] = Valid Range : 0 to 8
d [Number of data code words per one line]
Valid Range : 01 to 30
00 : Automatic (Width varies depending on number of data)
e [Number of line per symbol]
Valid Range : 03 to 90
00 : Automatic (Height varies depending on number of data)
f [Code type]
0 : Normal, When omitted 0(can be omitted)
1 : Truncated
[Format](Data part)
<DN>mmmm,n...n
• Parameter
m [Number of data] = Valid Range : 1 to 2681 bytes
n [Print data] = Data

SATO CL6NX Specifications

General

Flash memory	2000 MB
Storage media	Flash
Internal memory	256 MB
Built-in barcodes	Code 39, Code 93, Code-128 Codabar Library, EAN13, EAN8, GS1 DataBar, Industrial 2/5, Interleaved 2/5, Matrix 2/5
Internal storage capacity	2 GB
Cables included	AC
Maximum roll diameter	220 mm
Maximum printing width	167.5 mm
Printing media thickness	0.08 - 0.268 µm
USB port	Yes
USB connector	USB Type-A / USB Type-B
Bluetooth version	3.0
Serial interface type	RS-232C
USB 2.0 ports quantity	2
Connectivity technology	Wired & Wireless
Wi-Fi	No
Display type	LCD
Product color	Black
Display diagonal	3.5 \
Display resolution	320 x 240 pixels
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 80 %
Type	POS printer
Print speed	10 ips
Print technology	Direct thermal / Thermal transfer
Maximum resolution	203 x 203 DPI

Weight and Dimensions

Depth	457 mm
Width	338 mm
Height	321 mm
Weight	20000 g
