315
[ESC+BX] DataMatrix (ECC200) (Compatible command)
ESC BX ParameterHexadecimal code
<1B>
16
<42>
16
<58>
16
aabbccddeeefffghh
Initial value Nil
When the power is OFF The set parameter is not maintained.
Valid range within items The set parameter becomes invalid.
Valid range and term of
command
Valid range between
items
The set parameter becomes invalid.
[Function]
Specifying DataMatrix (ECC200).
[Format] (Setup part)
<BX>aabbccddeeefffghh
• Parameter
a [Format ID]
Valid Range : 01 (Fixed)
b [Error correction level]
Valid Range : 20 (Fixed)
c [Cell width]
Valid Range : 01 to 99 (dot per cell)
d [Cell pitch]
Valid Range : 01 to 99 (dot per cell)
e [Number of cells per line]
Valid Range : 010 to 144
000 : (Auto setup)
f [Number of cell lines]
Valid Range : 008 to 414
000 : (Auto setup)
g [Mirror image]
Valid Range : 0 (Fixed)
h [Size of guide cell]
Valid Range : 01 (Fixed)
[Supplementary Explanation]
• 01 and 02 are designable for [Cell width] and [Cell Pitch]; however, they may not be read
properly. In this case, 00 will be an error.
• If 000 is specified for both [No. of cells per line] and [Number of cell lines], optimum matrix size
is set automatically based on the Number of data.
[Precautions during use]
• This is the command of the old specification. Recommend the use of <2D50>.
Parent topic 2D Code
