[ESC+BJS] Memory Card Status Print
ESC BJS ParameterHexadecimal code
<1B>
16
<42>
16
<4A>
16
<53>
16
Nil
Initial value Nil
When the power is OFF The set parameter is not maintained.
Valid range within items The set parameter becomes invalid.
Valid range and term of command
Valid range between items The set parameter becomes invalid.
[Function]
Printing status of memory card.
[Format]
<BJS>
[Coding Example]
<A>
<CC>1
<BJS>
<Z>
[Supplementary Explanation]
• This command is for printing status of memory card; therefore, it cannot be used in combination
with other commands.
• Status of memory card can be confirmed with a size of 68 mm in media width and 90 mm in
media length.
[Note]
• Do not turn the printer's power off when accessing to the memory. When the printer power is off
while memory accessing, the data in the accessed media may be corrupted.
Parent topic Memory Card Command
