SATO CL6NX - Example of Transmission Data

717
Example of transmission data
Following shows an example of transmission data.
(1) Print data
STX
<A>
<X22>,sato
<Q>0001
<Z>
ETX
71H 9CH
Following shows HEX data to be sent. CRC is shown with underline.
02 1B 41 1B 58 32 32 2C 53 41 54 4F 1B 51 30 30 30 31 1B 5A 03 71 9C
(2) Print speed Command <CS>
STX
<A>
<CS>2
<Z>
ETX
ECH 5EH
Following shows HEX data to be sent. CRC is shown with underline.
02 1B 41 1B 43 53 32 1B 5A 03 EC 5E
Parent topic Bluetooth
