181
[ESC+B] Barcode (Ratio 1:3)
ESC B ParameterHexadecimal code
<1B>
16
<42>
16
abbcccn...n
Initial value Nil
When the power is OFF The set parameter is not maintained.
Valid range within items The set parameter becomes invalid.
Valid range and term of
command
Valid range between items The set parameter becomes invalid.
[Function]
Specifies a barcode with a ratio of 1:3 between narrow bar and wide bar.
[Format]
<B>abbcccn...n
• Parameter
a [Barcode type] = Refer to table below
b [Narrow bar width] = Valid range : 01 to 36 dots
c [Barcode height] = Valid range : 001 to 999 dots
n [Print data] = Data
Barcode types (Ratio of module composition may not be available depending on the barcode.)
a Barcode type Description Ratio
0 CODABAR (NW-7) Set print data including Start/Stop character.
Start/Stop characters are [A, B, C, D, E, N, T, a, b, c, d, e, n, t,
*]. Note that scan result of the characters [E, N, T, a, b, c, d, e,
n, t, *] is [D, B, A, A, B, C, D, D, B, A, C].
e.g.) When barcode print data is [123], specify [A123A].
Barcode character pitch becomes enabled.
For print data, refer to the CODABAR (NW-7) code table.
1:3
1 CODE39 Set print data including Start/Stop character.
Start/Stop Character is [*].
e.g.) When barcode print data is [12345], specify [*12345*].
Barcode character pitch becomes enabled.
For print data, refer to the CODE39 code table.
1:3
2 ITF Specify print data in even-numbered digit.
If specifying in odd-numbered digit, add "0" to the head of print
data.
For print data, refer to the ITF code table.
1:3
3 JAN/EAN13 This barcode has no guard bars and no human-readable
characters
For print data specifications, refer to table of JAN/EAN13 code.
Fixed
(11,12,13
digits)
4 JAN/EAN8 This barcode has no guard bars and no human-readable
characters
For print data specifications, refer to table of JAN/EAN8 code.
Fixed
(7,8 digits)
5 Industrial 2of5 Barcode character pitch is enabled. 1:3
To Next Page
