50
[ESC+(] Reverse Color Print
ESC ( ParameterHexadecimal code
<1B>
16
<28>
16
aaaa,bbbbb
Initial value Nil
When the power is OFF The set parameter is not maintained.
Valid range within items The set parameter becomes invalid.
Valid range and term of
command
Valid range between items The set parameter becomes invalid.
[Function]
Specifying black and white reverse print.
[Format]
<(>aaaa,bbbbb
• Parameter
a [Specification of reverse area in horizontal direction] = Valid range: Refer to the table below
b [Specification of reverse area in vertical direction] = Valid range: Refer to the table below
[Coding Example]
Reverse area in horizontal direction: 200, Reverse area in vertical direction: 70
<A>
<V>50<H>50<P>2<L>0202<XM>ABC
<V>50<H>50<(>200,70
<Q>2
<Z>
V50 (dots)
H50 (dots)
200 (dots)
70 (dots)
Label feed direction
[Supplementary Explanation]
• Set this command next after the firm data string to be inversed. If it is set prior to the firm data
the data will be printed in black without inverse.
• To set print start position, specify Horizontal Print Position <H> and Vertical Print Position <V>
prior to this command.
• When the print start position exceeds the printing area, printing will not be performed due to
command error.
[Note]
• For setting, keep the black print area under 30% of overall label.
To Next Page
