Connector pin assignment
14 pin external signal interface
Pin
no.
Signal name Contents I/O Level Electric condition
(voltage, current (MAX))
1 Paper end Output when paper
end is detected.
Open collector output Low 50V
50mA
2 GND SIGNAL GROUND ― ― ―
3 Ribbon end Output when
detect ribbon end.
Open collector output Low 50V
50mA
4 Machine error Output when Head
open, Head error
or communication
error occurs.
Open collector output Low 50V
50mA
5 Print start
(PRIN)
Print one label
every time when
this signal is input.
Input Low High: Hi-Z
Low:-15mA<,0V
6 Print end
(PREND)
*1
,
*2
Output when a
label is print.
Open collector output Low 50V
50mA
7 Re-print
(PRIN2)
Print the same
content again by
input this signal.
Input Low High: Hi-Z
Low:-15mA<,0V
8
EXT5V_IN
*3
For external power
supply
Input ― 5V
9
Offline
*4
Output when
printer is offline.
Open collector output Low 50V 50mA
10 Ribbon near
end
Output when
detect ribbon is
near end.
Open collector output High 50V 50mA
11 ― ― ― ― ―
12 +24V ― ― ― 2A
13 +5V ― ― ― 500mA
14 ― ― ― ― ―
－
Waiting for
Dispenser
completion
signal
*5
,
*6
Outputs signal
while waiting
for dispenser
completion signal
Open collector output Low 50V
50mA
－
Label near
end
*5
Output when
detect label near
end
Open collector output High 50V
50mA
*1 Select TYPE I-TYPE IV for No.6 pin “PREND” output signal. For details, refer to external signal type in Basic
specification.
*2 No. 6 pin ”PREND” output signal is not output when “0” is specified as number of cuts for cut unit number
command in cutter operation.
*3 When SW14 on IF board is set to 2-3, the printer operates by power supply from EXT5V_IN(No. 8 pin).
When set to 1-2 side, the printer operates by internal power supply (Set to 1-2 side as shipment settings).
