Reissuing EXT signal
Following signal types are available in the [Interface] > [External I/O] > [Signals] > [EXT Mode].
Type Operation
TYPE
Ⅰ
Print end signal (PREND) is “High” before printing labels. The signal level is
“Low” after the completion of print and will be “High” 20ms later.
TYPE
Ⅱ
Print end signal (PREND) is “Low” before printing labels. The signal level is
“High” after the completion of print and will be “Low” 20ms later.
TYPE
Ⅲ
Print end signal (PREND) is "High" before printing labels. The signal
level is "Low" from the start to the end of print and will be "High" after the
completion of print.
TYPE
Ⅳ
Print end signal (PREND) is "Low" before printing labels. The signal
level is "High" from the start to the end of print and will be "Low" after the
completion of print.
Reissuing EXT signal
Following settings are available in the [Interface] > [External I/O].
Enable: Reprint the same content
Disable: No reprint
Dispenser completion signal
Sets pin number for dispenser completion signal in [Interface] > [External I/O] > [Signals] > [Outputs]
settings.
When pin no. is set: Outputs dispenser completion signal when dispenser motion is completed. (Sets
signal level to Low)
When set, it works with the sequence of dispenser completion signal.
When pin number is not set: Dispenser completion signal state won’t change while waiting for
dispenser motion to complete.
Label Near end
Sets pin number for Label near end in [Interface] > [External I/O] > [Signals] > [Outputs] settings.
When pin No. is set: Outputs label near end when detected label near end. (Sets signal level to
Low )
When set, it works with the sequence of label near end.
When pin number is not set: Label near end state will not change while for label near end.
Parent topic External signal interface
