SATO CL6NX Programming Reference

91
[ESC+OA] OCR-A font
ESC OA ParameterHexadecimal code
<1B>
16
<4F>
16
<41>
16
n...n
Initial value Nil
When the power is OFF The set parameter is not maintained.
Valid range within items The set parameter becomes invalid.
Valid range and term of
command
Valid range between items The set parameter becomes invalid.
[Function]
Specifying OCR-A font.
[Format]
<OA>n...n
• Parameter
n [Print data] = Data
[Coding example]
<A>
<V>100<H>100<P>2<L>0202<OA>ABC
<Q>2
<Z>
[Supplementary Explanation]
• Refer to the table below for font size of each head density.
[Font size table]
Head density Font size (dots)
203 dpi (8 dots/mm) W15 x H22
305 dpi (12 dots/mm) W22 x H33
609dpi (24 dots/mm) W44 x H66
[Valid Commands]
Print position <V> <H>
Modification <P> <L> <%> <F> <&> </> <0> <WD>
Barcode <D><d> <BL><d>
Calendar
<WA>
*1
*1 This command requires optional calendar IC.

SATO CL6NX Specifications

General

Flash memory	2000 MB
Storage media	Flash
Internal memory	256 MB
Built-in barcodes	Code 39, Code 93, Code-128 Codabar Library, EAN13, EAN8, GS1 DataBar, Industrial 2/5, Interleaved 2/5, Matrix 2/5
Internal storage capacity	2 GB
Cables included	AC
Maximum roll diameter	220 mm
Maximum printing width	167.5 mm
Printing media thickness	0.08 - 0.268 µm
USB port	Yes
USB connector	USB Type-A / USB Type-B
Bluetooth version	3.0
Serial interface type	RS-232C
USB 2.0 ports quantity	2
Connectivity technology	Wired & Wireless
Wi-Fi	No
Display type	LCD
Product color	Black
Display diagonal	3.5 \
Display resolution	320 x 240 pixels
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 80 %
Type	POS printer
Print speed	10 ips
Print technology	Direct thermal / Thermal transfer
Maximum resolution	203 x 203 DPI

Weight and Dimensions

Depth	457 mm
Width	338 mm
Height	321 mm
Weight	20000 g
