42
[ESC+F] Sequential number
ESC F ParameterHexadecimal code
<1B>
16
<46>
16
aaaabcccc(,dd,ee,f)
Initial value Nil
When the power is OFF The set parameter is not maintained.
Valid range within items The set parameter becomes invalid.
Valid range and term of
command
Valid range between items The set parameter becomes invalid.
[Function]
Specifying prior to the data specification command of font or barcode, and printing specified data in
a sequential order.
[Format]
<F>aaaabcccc(,dd,ee,f)
• Parameter
a [Print quantity specification of identical contents] = Valid range : 1 to 9999
b [Increasing and decreasing specification]
+ : Addition
- : Subtraction
c [Setting of increasing and decreasing value] = Valid range : 1 to 9999
d [Valid digit number for sequential number] = Valid range : 1 to 99 When omitted: 8 (omissible)
e [Low-order invalid digit number] = Valid range : 0 to 99 When omitted: 0 (omissible)
f [Specification of Decimal/Hex sequential number]
0 : Decimal number When omitted: 0 (omissible)
1 : Hexadecimal
[Coding Example]
Print quantity specification of identical contents: 1, Increasing and decreasing specification: +,
Setting of increasing and decreasing value: 1, Valid digit number for sequential number: 5, Low-
order invalid digit number: 0
<A>
<V>100<H>100<P>2<L>0202
<F>1+1,5,0<XU>10000
<Q>2
<Z>
[Supplementary Explanation]
• Sequential number can be specified up to 8 points per format.
• Next print data from <F> command will be the initial value of sequential number.
• Specify the required number of digits for sequential number to print it properly.
• Specification of Black/White Reverse Print <(> is not valid for sequential numbered data.
• Auto Linefeed <E> is not available.
• Need to print font or barcode to print sequential number.
