[ESC+2D70] Aztec Code
ESC 2D70 ParameterHexadecimal code
<1B>
16
<32>
16
<44>
16
<37>
16
<30>
16
,a,bb,cc,dd,e,f...f
Initial value Nil
When the power is OFF The set parameter is not maintained.
Valid range within items The set parameter becomes invalid.
Valid range and term of
command
Valid range between items The set parameter becomes invalid.
[Function]
Specifies Aztec Code.
[Format] (Setup part)
<2D70>,a,bb,cc,dd,e,f...f
• Parameter
a [Symbol Type]
0
:
Full Range Symbol
1
:
Compact Symbol
b [ECC Percentage]
0
:
Default error correction level
01 to 99
:
Error correction percentage
c [Symbol Size]
0
:
Automatic minimization
1 to 4
:
1 to 4 – layer (Compact Symbol) * Following symbol size table reference.
4 to 32
:
4 to 32 – layer (Full Range Symbol) * Following symbol size table reference.
d [Number of symbols for structured append]
0
:
Encodes without append
1
:
Automatic Setting
2 to 26
:
Append structured blocks
e [Message ID]
Y
:
Specify Message ID for structured bound symbol
N
:
No Message ID
f [Message ID for structured bound symbol]
Printable ASCII string (0x21 to 0x7E) with maximum 24 bytes.
[Format] (Data part)
<DS>n..n
// for ASCII data
<DN>mmmm,n..n
// for Binary data
• Parameter
m [Number of Data] = 0001 to 1914
- Set this parameter when Print data are in Binary.
n [Print data] = Data
- When selecting [1BH], make sure to specify [1BH,1BH].
- When selecting [FNC1], make sure to specify [1BH,30H]
- When selecting [ECI], make sure to specify [1BH,*]. (‘*’ refers from 31H to 36H. )
