270
[ESC+2D50] DataMatrix (ECC200)
ESC 2D50 ParameterHexadecimal code
<1B>
16
<32>
16
<44>
16
<35>
16
<30>
16
,aa,bb,ccc,ddd
Initial value Nil
When the power is OFF The set parameter is not maintained.
Valid range within items The set parameter becomes invalid.
Valid range and term of
command
Valid range between items The set parameter becomes invalid.
[Function]
Specifying DataMatrix Code (ECC200).
[Format] (Setup part)
<2D50>,aa,bb,ccc,ddd
• Parameter
a [Horizontal cell size] = Valid Range
:
01 to 99 dots
b [Vertical cell size] = Valid Range
:
01 to 99 dots
c [Number of cell in one line]
Valid Range
:
010 to 144
000
:
(Auto-setting)
d [Number of cell lines]
Valid Range
:
008 to 144
000
:
(Auto-setting)
[Format] (Data part)
<DN>mmmm,n...n
• Parameter
m [Number of data] = Valid Range
:
1 to 3116
n [Print data] = Data
* When print 7EH, specify "7EH, 7EH"
* If Parameter other than above is specified or print data does not match, printing is not performed.
[Coding Example]
Horizontal cell size: 3 dots, Vertical cell size: 3 dots
<A>
<V>100<H>200<2D50>,03,03,000,000
<DN>0010,0123456789
<Z>
To Next Page
