383
[ESC+/N] Registration of Field
ESC /N ParameterHexadecimal code
<1B>
16
<2F>
16
<4E>
16
,aa,bb
Initial value Nil
When the power is OFF The set parameter is not maintained.
Valid range within item The set parameter is valid until the next valid setting.
Valid range and term of
command
Valid range between items The set parameter is valid until the next valid setting.
[Function]
Registering items within the field of Registration of Format <YS>.
[Format]
</N>,aa,bb
• Parameter
a [Field number] = Valid Range
:
1 to 99
b [Digit number of print] = Valid Range
:
1 to 99
[Coding Example]
<A>
<CC>1
<YS>,1
</N>,1,3
<%>0<V>100<H>200<P>2<L>0101<XM>ABC
</N>,2,5
<%>0<V>200<H>200<P>2<L>0101<OA>12345
</N>,3,8
<%>0<V>300<H>40<B>40208049123456
<Z>
[Supplementary Explanation]
• Specify the value of [Field number] in ascending order.
• Specify Vertical Print Position <V> and Horizontal Print Position <H> for each field. If not, default
value will be set.
• Specification of digit number when printing external character.
External code H, one external character has 4 digits; thus, three external characters make 12
digits for printing.
External code B, one external character has 2 digits; thus, three external characters make 6
digits for printing.
• Use this command and Registration of Format <YS> as a pair.
• Due to the memory capacity limit, it may not save up to 99 registries.
• The error occurs when specifying unused or specifying the slot which the printer is allocated.
[Note]
To Next Page
