SATO CL6NX Programming Reference

618
Combination of interface
Interfaces can be combined as described in the following chart.
CONT PCB KB-PCB IF-PCB (COMBO) Optional
PCB
USB LAN Bluetooth NFC RS-232C IEEE1284 EXT Wireless
LAN
USB ○ ○ ○ ○ ○ ○ ○CONT PCB
LAN ○ ○ ○ ○ ○ ○
△
Bluetooth ○ ○ ○ ○ ○ ○ ○KB-PCB
NFC ○ ○ ○ ○ ○ ○ ○
RS-232C ○ ○ ○ ○ ○ ○ ○
IEEE1284 ○ ○ ○ ○ ○ ○ ○
IF-PCB
(COMBO)
EXT ○ ○ ○ ○ ○ ○ ○
Optional
PCB
Wireless
LAN
○
△
○ ○ ○ ○ ○
[○: Configurable,
△:
Select]
[Supplementary explanation]
• Although it is not possible to use LAN with Wireless LAN, it is possible to choose LAN or
Wireless LAN from LCD screen. Please refer to [Switching LAN and WLAN] for details.
• Corresponding to the IEEE1284 high-speed IF board (COMBO). IF board automatic recognize.
Parent topic Overview

SATO CL6NX Specifications

General

Flash memory	2000 MB
Storage media	Flash
Internal memory	256 MB
Built-in barcodes	Code 39, Code 93, Code-128 Codabar Library, EAN13, EAN8, GS1 DataBar, Industrial 2/5, Interleaved 2/5, Matrix 2/5
Internal storage capacity	2 GB
Cables included	AC
Maximum roll diameter	220 mm
Maximum printing width	167.5 mm
Printing media thickness	0.08 - 0.268 µm
USB port	Yes
USB connector	USB Type-A / USB Type-B
Bluetooth version	3.0
Serial interface type	RS-232C
USB 2.0 ports quantity	2
Connectivity technology	Wired & Wireless
Wi-Fi	No
Display type	LCD
Product color	Black
Display diagonal	3.5 \
Display resolution	320 x 240 pixels
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 80 %
Type	POS printer
Print speed	10 ips
Print technology	Direct thermal / Thermal transfer
Maximum resolution	203 x 203 DPI

Weight and Dimensions

Depth	457 mm
Width	338 mm
Height	321 mm
Weight	20000 g
